apply to system | tig precision longitudinal seam system, tig precision ring seam system |
applicable welding mode | tig, microbeam plasma |
suitable workpiece material | stainless steel |
weld form | corner seam, longitudinal seam, ring seam |
the thickness of the workpiece | the following 3 mm |
application industry | instrument, instrument, bellows industry, etc |
system features:
in view of the workpiece situation and weld form of the industry, we specially designed two sets of precision ring seam and precision longitudinal seam system, unique mechanical design, high precision of each part, can meet the welding requirements of the industry products.
due to the product requirements, the workpiece is basically ultra-thin type ≤3mm, for the longitudinal seam can be used tig or micro beam plasma, ring seam using tig, can obtain good quality, beautiful forming weld.
for circular seam, because the workpiece can not achieve absolute roundness, therefore, the system has avc function, can realize automatic arc length adjustment.
plc control welding parameters and procedures, high degree of automation.
