the application of information
the product is an innovative gas storage and supply platform designed for the industrial, scientific and medical sectors to be more economical, more convenient for distribution and more reliable, more efficient and more economical than similar dewar gas supplies.
relative improvement of dewar products:
provide on-site filling solutions for cylinder users;
fast charging capacity;
realize uninterrupted gas supply;
long product retention time;
avoid frostbite caused by handling low-temperature gases;
avoid cylinder loss or deterioration of the trouble.
insulation mode: high vacuum multilayer winding insulation;
◆ workpiece diameter: ¢850 ~ 1600mm;
◆ structure: double layer, vertical
◆ product specifications: 1m3, 2m3, 3m3;
◆ working pressure: ≤ 3.0mpa;
◆ medium: lo2, ln2, lar, lng;
◆ application: industry, diet, science and medicine, etc.
◆ implementation standard: gb
double flame automatic wire feeding brazing copper pipe technology;
the brazing is soft brazing, and the solder is about 4mm tin-based solder with brazing agent.
with cooling water spray system, brazing quality and workpiece deformation quality.
greatly improve the production efficiency, reduce the intensity of operation.
