description
rgv,is known as rail guided vehicle,because rgv can reciprocate and shuttle on a pre-set right-angle track.
performance
rgv can realize material handling in multiple and different stations.it is one of the carriers for an intelligent production line and has the characteristics of heavy load,fast running speed,strong flexibility with stable and reliable system.safety protection.introducing 5g technology for multiple standard agv reliable synchronization to meet various non-standard application.
technical parameter
dimension | customized | |||||
speed | 0~160m/min | |||||
motion efficiency | 0~60pallet/hour/set | |||||
positioning accuracy | ±5mm | |||||
operation mode | manual, stand-alone automatic and synchronized automatic control | |||||
horizontal motion speed control | variable frequency control | |||||
power | motor and reducer | |||||
rayload | 100kg-10000kg | |||||
power supply | isolated conductor rail(icr),lithium battery | |||||
rail | aluminum alloy or steel,built-in icr for safety assurance |
