pipe products
high speed band saw
  • hotline: 86 (0)512-57328118

  • mailbox:sales@huahengweld.com

    description

    applicable materials:carbon steel,alloy steel,low temperature steel,stainless steel,duplex stainless steel

    structure type:horizontal gantry double column,double oil cylinder

    clamping system:automatic hydraulic bilateral centering clamping,two pairs of clamps distributed in front of the sawing machine

    it has the functions of automatic clamping,automatic feeding,automatic stop when the belt is broken

    saw cutting speed,feed speed,steplessly adjustable within a given range

    the cutting tool adopts thin bimetallic band saw blade,with narrow incision,less consumables,and less power required.it is a high-efficiency cutting equipment with significant material saving and energy saving.

    applicable pipe diameter:dn50-600(φ57-630mm)

    applicable wall thickness:5-90mm

    optional grating ruler cnc fixed length(cmbs-24)


    technical parameter

    input voltage

    380v 50hz

    cutting method

    saw blade cutting, water cooling

    rated power

    11.5kw

    weight capacity

    5000kg

    hydraulic motor power

    1.5kw

    saw belt tension

    hydraulic tightening/releasing

    main motor power

    7.5kw

    saw belt speed

    17-85m/min

    cooling motor

    0.125kw

    equipment weight

    about 3900kg

    control method

    plc touch screen

    saw blade size

    6980mm×41mm×1.3 mm
