pipe series tooling is mainly used for pipe-pipe, pipe-flange, pipe-elbow, pipe-tee and other forms of pipe welding. the open-type pipe wrench with patented technology is used to realize automatic centering of pipes and pipe fittings, electric (manual) clamping, and stable rotation, equipped with control means such as arc pressure monitoring, to realize automatic welding of prefabricated bottoming, filling and covering of pipelines.
patented technology products
effectively solve the problem of axial movement of the pipe
effectively solve the problem of pipe radial movement
the open design makes it easier and more convenient to hoist long pipes
electric three-jaw clamping, automatic centering, reducing the labor intensity of workers
ac servo motor clamping driving, large speed range, fast dynamic response, high precision
gear/sprocket transmission, high transmission efficiency, large bearing capacity, and can adapt to harsh working conditions
model | kb230 | kb370 | kb500 | kb630 | kb760 |
maximum rotation speed | 3.7 | 4.3 | 3.5 | 2 | 2.26 |
maximum driving torque | 2500 | 2900 | 7000 | 20000 | 20000 |
pipe diameter range | ф34-ф230 | ф60-ф370 | ф168-ф500 | ф219-ф630 | ф219-ф760 |
carrying capacity | 550 | 1300 | 3000 | 5000 | 5000 |
electric power | 1.3 | 1.3 | 3.0 | 4.4 | 4.4 |
center high | 600 | 780 | 950 | 1190 | 1280 |
dimensions (l*w*h) | 550*440*830 | 774*500*1135 | 1000*630*1420 | 1750*1200*1945 | 2100*1090*2140 |
clamping method | electric | electric | electric | electric | manual |
