description
technical parameter
name | iorbital401 |
power type | inversion |
welding current | 5~400a |
duty cycle (20 degrees celsius) | 400a60% 310a100% |
no-load voltage | 72v |
input voltage | 3*380v±10% 50/60hz |
input power | 13.5kva |
power cooling | air cooling |
monitor | 6.5 inch chinese/english display |
programmatically | panel programming |
show | wired controller/panel/chinese and english real-time parameter display |
programmable storage | 100group |
expert parameter storage | prestore |
partitionable | 20 |
torch cooling | external circulating water cooling |
water tank model | cw-04 water tank |
power supply weight（kg） | 260 |
manufacturing standards | gb15579-2004 |
insulation safety class/standard | h/ip23 |
size l*w*h（mm） | 710*500*1500 |
