self-fusing thin-wall pipe welding system
tc series sealed orbital tube welding head
  • hotline: 86 (0)512-57328118

  • mailbox:sales@huahengweld.com

    description

    the welding head is a special welding head for all-position automatic tungsten arc welding(without welding wire)designed for the butt joint of various pipe fittings.before welding,the sealing cavity is filled with protective gas to ensure that the welding seam is well protected.and according to customer requirements,we can customize the compound fixture within the pipe diameter range.this fixture system can ensure the precise positioning of the welded parts without the need for positioning spot welding,so as to provide customers with high-efficiency and high-quality special welding guns.this machine can be used with tube master200,iorbital4000,iorbital5000 program-controlled welding power sources,and can precisely realize all-position tig tube/tube welding,with high reproducibility of welding results and ideal welding results.mainly used in electronics,instrumentation,pharmaceutical,engineering installation,military and nuclear power industries.

    performance

    the main part of the welding head is made of aluminum, and the structure is light;

    the sealed design is adopted, and the protection effect is more sufficient;

    patented flexible automatic centering fixture, precise positioning;

    suitable for tube welding of thin-walled carbon steel, stainless steel, titanium and titanium alloys;

    self fusion welding method;

    equipped with operation buttons on the welding head, the welding head is easy to use and suitable for on-site installation.

    technical parameter

    tc26

     tc36

    tc76tc156

    tc-2

     tc-3

    tc-4

    weldable material

    carbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloycarbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloy

    weldable pipe diameter(mm)

    φ6~φ22(1/4″~7/8″

    φ6~φ32(1/4″~1 1/4″ )

    φ19.05~φ63.5(3/4″ 2 1/2″ φ50.8~φ168.3(2″~65/8″)

    φ12.7~φ50.8(1/2″~3″ )

    φ19.05~φ7(3/4″~3″ )

    φ38.1~φ101.6(2″~4″)

    tungsten electrode diameter(mm)

    ¢1.0;¢1.6

    ¢1.6;¢2.4

    ¢1.6;¢2.4

    ¢2.4;¢3.2

    ¢1.6;¢2.4

    ¢1.6;¢2.4

    ¢2.4;¢3.2

    spinning speed(rpm)

    0.6~12

    0.3~6

    0.2~6

    0.06~1.2

    0.24~4.8

    0.2~4

    0.095~1.9

    protective gas

    argon

    argon

    argonargon

    argon

    argon

    argon

    cooling method

    water cooling

    water cooling

    water coolingwater cooling

    water cooling

    water cooling

    water cooling

    cooling flow(ml/min)

    ≥300

    ≥300

    ≥300≥300

    ≥300

    ≥300

    ≥300

    rated current

    60a  duty cycle 60%

    65a  duty cycle 60%

    75a  duty cycle 60%100a  duty cycle 60%

    75a  duty cycle 60%

    75a  duty cycle 60%

    100a  duty cycle 60%

    main dimensions(mm)








    a

    80

    98

    145295

    135

    160

    195

    b

    40

    47

    72150

    65

    79

    97

    c

    40

    41

    4361

    38

    38

    57

    d

    340

    360

    412630

    426

    453

    497

    weight(kg)

    2.0(without cable)

    2.0(without cable)

    3.0(without cable)

    10.5(without cable)

    2.5(without cable)

    3.5(without cable)

    6(without cable)

    dimensions(mm)

    340*80*40

    360*120*41

    412*165*43630*330*61

    426*155*38

    453*177*38

    497*230*57
