the positioner series tooling can be used for various automatic welding or manual welding to realize pipe butt joint, pipe end face welding and various welding forms such as shafts, discs, and cylinders. it has compact structure, beautiful appearance and light weight. convenient operation and other advantages, it is an ideal welding auxiliary equipment for pressure vessels, metallurgy, electric power, chemical machinery, metal structures and other industries.
project | parameter | |
number of positioner axes | 2 axes (flip axis, rotary axis) | |
range of motion | flip axis | 270º(-135º～ 135º) |
rotary axis | 480º(-240º～ 240º) | |
maximum action speed | flip axis | 140º/sec |
rotary axis | 115º/sec | |
maximum load | 500kg | |
work surface size | ø500mm | |
maximum center of gravity | 350mm | |
start, stop allowable torque | flip axis | 3920nm |
rotary axis | 3000nm | |
reduction ratio | flip axis | 129 |
rotary axis | 156 | |
quality | 345kg | |
repeatability | 0.1mm | |
