technical parameter
| equipment model | jz-hw-1000w | jz-hw-1500w |
| laser generator | 1000w | 1500w |
| laser wavelength | 1070nm | 1070nm |
fiber core diamete | 20μm | 50μm |
fiber length | standard configuration 10m | standard configuration 10m |
| operation mode | continuous/modulation | continuous/modulation |
| galvanometer width | 0.5-6mm | 0.5-6mm |
| galvanometer scanning speed | ≤8000mm/s | ≤8000mm/s |
welding speed | 0-120mm/s | 0-120mm/s |
| refrigeration device | intelligent dual-temperature water chiller | intelligent dual-temperature water chiller |
| operating ambient temperature range | 15-35°c | 15-35°c |
humidity range of working environment | <70% without condensation | <70% without condensation |
| thickness of welding material | ≤3mm | ≤5mm |
welding gap requirements | ≤0.5mm | ≤0.5mm |
| working voltage | 220v±10% | 380v±10% |
overall power | ≤5kw | ≤6kw |
| product size | 1350mm*600mm*1300mm | 1350mm*600mm*1300mm |
