the welding equipment is installed and fixed into the container to form a pipeline prefabricated mobile workstation, suitable for small and medium-sized short-term projects
basic configuration: pipeline welding workstation simple logistics conveying system container
production efficiency: high (prefabrication of small assembly lines can be carried out on the construction site)
on-site equipment installation performance: good (main equipment, spreaders and power distribution are installed and fixed in the container, and the logistics site is placed)
suitable for short-term projects of small and medium projects
serial number | equipment (material) name | specifications | unit | quantity | remark |
1 | pipe welding workstation (includes the following) | pcws-24 | set | 1 | pipe-fitting butt welding |
2 | compression positioner type pipe welding workstation | pqyj24-tms | tower | 1 | fits 2-24" pipe diameter |
3 | pipe wrench pipe welding workstation | kb370tm | set | 1 | fits 2-14" pipe diameter |
4 | specially modified container | 6058x2438x2896mm | indivual | 1 | retrofitting electrical systems, lighting and ventilation systems |
