this welding head is a special welding head specially designed for tube/pipe tig welding,suitable for automatic welding of tube/pipe in the form of narrow spacing.it can weld various pipes/pipes such as carbon steel and stainless steel.the diameter of the tube ranges fromφ32 toφ51mm,and two methods of wire filling or self-melting can be selected.the arc length and yaw function can be adjusted automatically.it can be used in conjunction with iorbital5000 programmable welding power source,which can precisely realize all-position tig tube/tube welding,with high reproducibility of welding results and ideal welding results.mainly used in chemical,food,boiler,military and nuclear power industries.
the main structure has three parts:rotating system,clamping device,transmission system;
the main part is made of aluminum,the structure is light,and the caliper-type clamping method can be adjusted arbitrarily for different pipe diameters;
adopt backlash-free gear transmission design,stable rotation,small moment of inertia,and small working environment at high temperature,no jamming phenomenon;
electric arc length yaw design,suitable for multi-pass welding process requirements;
suitable for pipe welding of medium-thick-wall carbon steel and stainless steel;
circulating water cooling,long continuous working time;
self-melting and wire welding;
it is widely used in the field installation of various joints such as pipe and pipe elbow.
applicable pipe diameter(mm) | φ32~φ51 |
tungsten electrode diameter(mm) | φ3.2 |
wire diameter(mm) | φ1.0 |
welding speed(rpm) | 0.25~5.02 |
cooling method | water cooling |
main dimensions of the head(mm) | |
a | 128 |
b | 155 |
c | 85~97 |
d | 78 |
e | 59 |
f | 360 |
weight(kg) | 5 |
