全国tc-500/tc-5h orbital welding head
  • hotline: 86 (0)512-57328118

  • mailbox:sales@huahengweld.com

    description

      the welding head is a special welding head for orbital automatic tungsten arc welding(without welding wire)designed for the butt joint of various pipe fittings.before welding,the sealing cavity is filled with protective gas to ensure that the welding seam is well protected.and according to customer requirements,we can customize the compound fixture within the pipe diameter range.this fixture system can ensure the precise positioning of the welded parts without the need for positioning spot welding,so as to provide customers with high-efficiency and high-quality special welding guns.this machine can be used with tube master200,iorbital4000,iorbital5000 program-controlled welding power sources,and can precisely realize orbital tig tube/tube welding,with high reproducibility of welding results and ideal welding results.mainly used in electronics,instrumentation,pharmaceutical,engineering installation,military and nuclear power industries.

    performance

      the main part of the welding torch is made of aluminum, and the structure is light;

      the sealed design is adopted, and the protection effect is more sufficient;

      patented flexible automatic centering fixture, precise positioning;

      suitable for pipe welding of thin-walled carbon steel, stainless steel, titanium and titanium alloys;

      self fusion welding method;

      equipped with operation buttons on the welding torch, the welding torch is easy to use and suitable for on-site installation.


    technical parameter

    tc-500

    tc-5h

    weldable material

    carbon steel, stainless steel, titanium alloy

    carbon steel, stainless steel, titanium alloy

    weldable pipe diameter(mm)

    φ6~φ12.7    (1/4″~1/2″)

    φ3~φ12.7

    tungsten electrode diameter(mm)

    φ1.0

    ¢1.6

    spinning speed(rpm)

    0.6~12

    0.7~14.2

    protective gas

    argon

    argon

    cooling method

    air cooling

    air cooling

    cooling flow(ml/min)



    rated current

    30a  duty cycle 60%

    30a  duty cycle 100%

    main dimensions(mm)



    a

    65

    57

    b

    24

    51

    c

    12.5

    38

    d

    314

    186

    weight(kg)

    1.3(without cable)

    1(without cable)

    dimensions(mm)

    314×65×42

    186*57*38
