    description

    overall project introduction:

    the entire warehouse of the project warehouse covers an area of 119.43m*69m=8240㎡. the left side of the platform on the first floor of the warehouse is the storage area, and the right side is the storage area. the overall building structure is two floors, and the other two floors are built with a steel platform mezzanine. ; among them, the first floor is mainly the storage area for vertical warehouses and pallets, the left side of the second floor is 4000 square meters for spare parts storage area, the right 1800 square meters is the storage area for vertical warehouses and whole pallets, and the second-floor platform mezzanine is for spare parts distribution and whole pallets. storage area; after the system layout is completed, it can meet the storage capacity of 10,488 pallets of pallets and the storage capacity of 33,000 boxes of spare parts.


    item storage location description:

    pallet (including goods) size: 1200l*1000w*(0~1300)hmm, load 500kg, 6934 storage spaces (first floor)

    pallet (including goods) size: 1200l*1000w*(0~1800)hmm, load 500kg, storage space 1010 (first floor)

    pallet (including goods) size: 1200l*1000w*(0~1300)hmm, load 300kg, 2544 storage spaces (2nd floor)

    bulk cargo (return box including goods) size: 600l*400w*300h (mm), weight 10kg, 1100 shelves, 30 spaces per shelf, about 33,000 total storage spaces (second floor)


    project instruction:

    1. location: kunshan, jiangsu;

    2. the total amount exceeds 90 million;

    3. 23 stacking cranes, over 100 wooden cows and flowing horses, over 1000 elevators and conveyor lines in total;

    4. including the whole pallet three-dimensional warehouse, box-type sorting, goods-to-person dismantling and picking and other processes.
